Theatrical sound enjoyment


Low input lag and quick response
Control your TCL devices in a smart way


Connect the world
One list for all your discoveries


Google TV
Technical specifications
Basic Properties
Brand: TCL
Category: TV
Family: C
Series: C645
Year: 2023
Product Type
Flat/Curved: Flat
Screen Type: LCD
Technology Type: Smart, UHD, QLED
Panel Type: DLED
General Information
Operation System: Google TV
Hand Free Voice Control: Yes
Google Assistant Built-in: Yes
Works with Alexa: No
IMAX Enhanced: No
Audio
Audio Power: 2 x 10 W
Dolby Atmos: Yes
DTS Premium Sound: DTS-HD Decoding, DTS Virtual: X
Sound Channel: 2.0 Channel
Bluetooth Audio Only: YES
Display
Resolution: 4K UHD
Panel Resolution: 3840*2160
Aspect Ratio: 16:9
Refresh Rate: 60Hz
Dolby Vision: Dolby Vision
HLG: Yes
HDR 10: YES
HDR 10+: YES
Contrast Ratio: 5000:1 (typ.)
Micro Dimming: Yes, 2040 Zones
Local Dimming: No
System Brightness - Full White: 300 nits (typ.)
Smart Service
Game Center: Yes
Online Video: Yes
Video Chat: Yes
Multi Visual: No
Gesture Control: No
Miracast (Wireless Display): Yes
Quick Settings: No
Connectivity
Bluetooth: Bluetooth 5.0
Wi-Fi: 2.4GHz/5GHz dual-band Wi-Fi 802.11 b/g/n 2T2R
RJ45: 1R
Composite Video Input: 1S - Mini RCA
Airplay2: No
Digital Audio Output (SPDIF): 1S--Optical
RF Input: 1S---IEC, 1S---F type (Differences in regions)
USB2.0 (5V-0.5A): 0
USB3.0 (5V-0.9A): 1
USB Subtitle: SUB/ASS/SRT/SMI
HDMI Inputs: 3S (HDMI2.1 *1 with ARC&EARC + HDMI2.0*2)
HDMI2. 1 (eARC&ARC): Yes, with Certification
HDMI2. 1(VRR): Yes, up to 1440P@120Hz (JP: TBD)
HDMI2. 1(ALLM): Yes
HDMI CEC: Yes, with Certification
AMD FreeSync: FreeSync
Dimensions & Weight
Vesa Wall Mount Support: Yes
Wall Mount Size: 200×200(mm)
Set Size with Stand (WxHxD): 185X603X957(mm)
Set Size without Stand (WxHxD): 80X558X957(mm)
Package Dimensions (LxWxH): 1100×128×665(mm)
Net Weight without Stand (Kg): 6.6
Net Weight with Stand (Kg): 6.7
Gross Weight with Packaging (Kg): 9
Product Type
Flat/Curved: Flat
Screen Type: LCD
Technology Type: Smart, UHD, QLED
Panel Type: DLED
Audio
Audio Power: 2 x 10 W
Dolby Atmos: Yes
DTS Premium Sound: DTS-HD Decoding, DTS Virtual: X
Sound Channel: 2.0 Channel
Bluetooth Audio Only: YES
Smart Service
Game Center: Yes
Online Video: Yes
Video Chat: Yes
Multi Visual: No
Gesture Control: No
Miracast (Wireless Display): Yes
Quick Settings: No
Dimensions & Weight
Vesa Wall Mount Support: Yes
Wall Mount Size: 200×200(mm)
Set Size with Stand (WxHxD): 185X603X957(mm)
Set Size without Stand (WxHxD): 80X558X957(mm)
Package Dimensions (LxWxH): 1100×128×665(mm)
Net Weight without Stand (Kg): 6.6
Net Weight with Stand (Kg): 6.7
Gross Weight with Packaging (Kg): 9
General Information
Operation System: Google TV
Hand Free Voice Control: Yes
Google Assistant Built-in: Yes
Works with Alexa: No
IMAX Enhanced: No
Display
Resolution: 4K UHD
Panel Resolution: 3840*2160
Aspect Ratio: 16:9
Refresh Rate: 60Hz
Dolby Vision: Dolby Vision
HLG: Yes
HDR 10: YES
HDR 10+: YES
Contrast Ratio: 5000:1 (typ.)
Micro Dimming: Yes, 2040 Zones
Local Dimming: No
System Brightness - Full White: 300 nits (typ.)
Connectivity
Bluetooth: Bluetooth 5.0
Wi-Fi: 2.4GHz/5GHz dual-band Wi-Fi 802.11 b/g/n 2T2R
RJ45: 1R
Composite Video Input: 1S - Mini RCA
Airplay2: No
Digital Audio Output (SPDIF): 1S--Optical
RF Input: 1S---IEC, 1S---F type (Differences in regions)
USB2.0 (5V-0.5A): 0
USB3.0 (5V-0.9A): 1
USB Subtitle: SUB/ASS/SRT/SMI
HDMI Inputs: 3S (HDMI2.1 *1 with ARC&EARC + HDMI2.0*2)
HDMI2. 1 (eARC&ARC): Yes, with Certification
HDMI2. 1(VRR): Yes, up to 1440P@120Hz (JP: TBD)
HDMI2. 1(ALLM): Yes
HDMI CEC: Yes, with Certification
AMD FreeSync: FreeSync
